Model	Phase number	Body length L(mm)	Holding torque (N.M)	Rated current (A)	Phase inductance (mH)	Phase resistance (Ω)	Rotor inertia (g·cm²)	Motor weight (kg)	Pin count
57SC10	2	74	1.0	3.5	1.57	0.43	260	0.8	4
57SC22	2	99	2.2	4.0	2	0.41	460	1.3	4
57SC30	2	122	3.0	5.0	3.73	0.82	720	1.48	4



1. Match our hybrid servo driver SC5780, or other manufacturers' drivers. We recommend DC 24Vdc, 36Vdc, or 48Vdc power supply; Please contact us for the drawings of the hybrid servo motor with brake.
2. The standard configuration for encoder resolution is 1000 lines, A B Two channel differential interface, other encoder resolutions, interface and motor shaft specifications can be customized.
3. The definitions of motor wiring and encoder wiring refer to the labeling instructions on the motor. Encoder extension cables are available in 3 meters, 5 meters, and 8 meters for selection. Other specifications of wiring harnesses can be customized.
